Decade of experience
With a decade of experience in the PCB industry, we have honed our ability to deliver exceptional products and services.
Our deep understanding of copper clad laminates allows us to provide tailored solutions that meet the unique requirements of your project. This expertise, coupled with our commitment to quality, ensures that you receive PCBs that exceed expectations.
Printed Circuit Magic
Our product portfolio boasts a cutting-edge range of Printed Circuit Boards, including complex HDI designs. We specialize in crafting technically sophisticated circuits that push the boundaries of performance and miniaturization. Our commitment to precision and innovation ensures that your most demanding electronic p
Printed Circuit Magic
Our product portfolio boasts a cutting-edge range of Printed Circuit Boards, including complex HDI designs. We specialize in crafting technically sophisticated circuits that push the boundaries of performance and miniaturization. Our commitment to precision and innovation ensures that your most demanding electronic projects are met with unparalleled quality and reliability.
Building T5 Eco System
Creating an environment for Electronics Manufacturers of Fair access to resources, transparent communication, and a commitment to promote resilience and unity within the ecosystem.
Endeavouring for Prosperity: Implementing Strategies to Generate Over 5 Million Direct and Indirect Jobs, Empowering Futures and Fuelling Economic Growth.
2-40 layers of quick-turn around FR4 with standard and high TG low and ultra low Dk, halogen free
Maximum inner and outer layer copper weight up to 12oz with 15oz of advance capability
ENIG, Immersion Tin, LF-HASL, OSP, Plated Heavy Au, Immersion Ag, ENEPIG, ASIG, Selective Hard and Soft Gold, Rhodium
4-40 Layer of standard available layer count
1+N+1, 2+N+2, 3+N+3, 4+N+4 Any layer connected (ALIC)
2.5 Mil minimum line width and space
600x450 as stand + Backplace panel size technology
4-20 Layers, 18um - 17um, 2.5mil minimum line width and space
RA-Copper, HTE Copper, FR-4, Polyamide, adhesive,
Smallest mechanically laser drilled hole 0.10 to 0.07 advance
We provide our customers with free access to import data, enabling them to stay informed about real-time developments and market trends. This data empowers businesses to make well-informed decisions, track industry movements, and gain valuable insights into competitive activities and global trade patterns. By offering this service at no cost, we aim to support our customers' growth, enhance transparency, and help them stay ahead in a rapidly evolving marketplace.
We also provide our customers with a comprehensive weekly newsletter designed to keep them informed about the latest trends and developments in the PCB (Printed Circuit Board) industry. This newsletter serves as a valuable resource, offering insights into the evolving market landscape, technological advancements, and supply chain dynamics.
A key feature of our newsletter is the detailed analysis of cost trends for the basic raw materials used in PCB manufacturing, such as copper, fiberglass, epoxy resin, and other essential components. We provide data-driven insights into the price fluctuations of these materials, helping customers understand the underlying factors influencing costs.
Our analysis covers a range of critical elements, including:
By offering this in-depth information, our newsletter equips customers with the knowledge they need to anticipate market changes, manage costs effectively, and make informed decisions for their business strategies. This value-added service reflects our commitment to empowering our customers with actionable insights to stay competitive and forward-thinking in the PCB industry.
We offer free training programs covering the entire PCB development process, from sourcing raw materials to delivering the final product. This comprehensive training is designed to provide participants with a holistic understanding of the PCB manufacturing lifecycle, empowering them with the skills and knowledge necessary to excel in the industry.
This training is ideal for engineers, students, manufacturers, and anyone interested in learning about PCB production, whether starting from scratch or enhancing existing expertise.
By providing this training at no cost, we aim to bridge the knowledge gap, support skill development, and contribute to the growth of a skilled workforce in the PCB industry. Our initiative reflects our commitment to fostering innovation and advancing the industry as a whole.
